Detailing for Increased Breakout Capacity of Steel Anchor Rods in Concrete Podium Slabs
Scott Fischer, P.E.
Multi-story light-frame structures are often built atop concrete podiums, and in areas of high seismicity the overturning restraint system used to secure shear walls in these buildings can produce very high tension demands on the concrete anchorage components of these systems. While the loads can be high, podium slabs tend to be fairly shallow (14” or less), and the design resistance calculated according to code provisions often isn’t enough. While anchor reinforcement detailing is address in ACI318, the form it would need to take in slab situations is not addressed. Recognizing this, a small group of practicing engineers, funded by a SEAONC Special Projects Initiative and supported by Simpson Strong-Tie, began an ambitions investigation into how to provide detailing (anchor reinforcing) that increases the breakout resistance of concrete anchors in podium slabs.
